PLASMA CUTTING MACHINE CG1 30K



Description:
  • The body is made of High strength Aluminium pressure die casting.
  • Abrasion resistant Manganese Steel Track.
  • A special plasma torch holder is supplied so that a vide range of Plasma torches can be used with this machine.
  • The electronic speed control provides a vide and precise range of speed control suitable for plasma cutting operation.
  • The max speed is almost 4 times of normal gas cutting trolley.
  • 4 Wheel design ensures jerk free smooth movement providing excellent cut finish.
  • Machine control output eliminates the need of operating the Plasma machine separately.
  • The plasma machine is turned on and off through this machine directly in sync with movement control.
  • Can use circle cutting attachment to cut circles.


  • Specifications
    CG1 30K
    Model No. Overall Supply Cutting Cutting Dia of Circle Weight
      Dimension Voltage Thickness Speed Cutting KG
      MM V/HZ MM MM/MIN MM
    CG1-30K 470x230x240 AC 200/50 Based on plasma source 50-4500 200-2000 12.5
